Antenna 15dBi 5.8Ghz Omni-Directional Vertical-Polarization
- In stock
- 3.00 LBS
Omni-Directional Vertical-Polarization Antenna
- Superior Performance
- Lightweight fiberglass radome
- All weather operation
- Center fed collinear array
- Heavy-duty steel mounting brackets
- Commercial grade, 15 dBi antenna
- Solid Brass Elements
- Integral N-Female connector
- Nickel-plated brass body for enhanced corrosion resistance: Nickel plating is the most weather-resistant, corrosion-resistant metal plating.
- High gain and superior VSWR. Optimized for the 5.8GHz ISM band. Suitable for Commercial Installations.
Rugged and Weatherproof: Fiberglass antenna
Nickel-plated brass body for enhanced corrosion resistance: Nickel plating is the most weather-resistant, corrosion-resistant metal plating.
Length: 157.4cm (5 feet and 2 inches). For international shipments, the length may increase the cost of shipping.
Omni directional dipole antenna: Radiates signal with a beam of 360 degrees; also receives signal from 360 degrees around it.
Compatibility with wireless standards & applications : This omni directional antenna's range of frequency band compatibility in the 5100~5800MHz frequency band range, its very low broadband VSWR at < 1.8 (lower VSWR is better), and impedance matching to 50 Ohm gear , makes it suitable and compliant for all the following applications:
- IoT wireless & M2M : Bluetooth , ZigBee , and ISM . Since it is vertically polarized , it is compatible with many machine to machine communication applications, remote monitoring, and telemetry applications.
- 5GHz Frequency Band: Suitable for 802.11ac WiFi and any other wireless application that uses the 5100 - 5800 GHz frequency band.
- Compatible with Bluetooth devices, Wireless Access Points & other wireless devices that have RP-SMA antenna jacks
- As Bluetooth antenna: Send or receive signal to devices in all directions (360-degree horizontal beamwidth )
- As client antenna: Connect to access points in any direction. Portable size: Easily fits in a laptop case.
Features & applications
- As access point antenna: Provides signal to clients in any direction (360-degree horizontal beamwidth )
- As client antenna: Connect to an access point in any direction
- Capable of extending your wireless range up to 300 meters.
- Suitable for outdoor or indoor wireless gear with RP-SMA-female.
|Power Handling||50 Watts|
|Beamwidth||H: 36 0degrees / V: 7 degrees|
|Operation Temp||-40 C ~ +80 C|
|Dimension||740*68 mm (29x2.7in)|
|Mounting||32 ~ 45 mm ( 1.2 ~1.75 inch )|
ROHS 3 & REACH compliant: Antenna, cable and connector are all compliant with ROHS 3 and REACH.
N-type Connector Characteristics and Details: Durable, weatherproof connection
- Our N connectors provide a consistent performance from 900MHz to 12.5 GHz.
- N-Female diameter is 0.620-inch (1.57 cm) . N-male inside diameter is 0.620-inch (1.57 cm)
- N-connector gender is counter-intuitive .
- N-Type connectors are the largest of the RF connector types , and are usually found on large antennas, especially for outdoor use.
- Our N-Type connectors feature threaded coupling mechanisms and are fully interchangeable with N-Type connectors made to the MIL-C-39012 specification. These connectors are used in all systems where excellent RF and mechanical performance is critical.
- N materials composition :
- Connector Body: Nickel-Plated Brass : The most corrosion-resistant of all plated brass alloys (better than gold-plated).
- Center Contact: Beryllium Copper, Gold Plated
- Crimp Ferrule: Copper, Nickel Plated
- Insulators: PTFE
