RJ45 Cable Gland Feed-Thru Waterproof Jack: Shielded Ground 7-inch Cable

$5.99
SKU:
IP67v3
Brand:

Availability:
In stock
Weight:
0.10 LBS
Write a Review

RJ45 Cable Gland Feed-Thru Waterproof Jack

RJ45 Weatherproof Coupler with 18cm cable:

  • Waterproof Jack Kit for CAT5e Ethernet cable with 18cm cable: Also fits CAT6 & CAT5
  • Outdoor rated and shielded Ethernet coupler for high speed 10BaseT, 100BaseT and 1000BaseT networks.
  • Field Replaceable Ethernet Connector/Coupler: Passes RJ45 Plug and seals cable to IP67
  • Shielded & Unshielded versions: RJ45 Receptacle mounted in a UV protected housing and a mating cable gland which passes an RJ45 connector and seals the cable to IP67 requirements.
  • Shielded version comes with a grounding cable: 7-inch (18cm): The shielded Cat5e cable and connectors provide maximum shielding against external EMI for consistent data communications.
  • Black versions are Shielded & Unshielded
  • Gray / beige version is unshielded
  • 12" Cat5e strain relieved cable

Ethernet connection system for high speed 10BaseT, 100BaseT and 1000BaseT networks. The system features a shielded RJ45 Receptacle mounted in a UV protected housing and a mating cable gland which passes an RJ45 connector and seals the cable to IP67 requirements. The system provides for quick and easy disconnect and reconnect of equipment. Because of its many unique design features and low cost, these are universal solutions for many industries where a sealed and waterproof, yet removable, ethernet connection is required. These include outdoor applications such as wireless equipment or video surveillance equipment and indoor applications such as equipment used in factory automation or harsh industrial processes.

SPECIFICATIONS:

IP Rate IP66
Cable Length 180mm+/- 10mm
Mounting Hole 20mm. Shielded version IP67v4RJS has 25mm mounting holes.
Spanner Size 27mm



Enables quick, easy disconnect and reconnect of equipment. Because of its many unique design features and low cost, these RJ45 cable glands are universal solutions for many industries where a sealed and waterproof, yet removable, Ethernet connection is required. These include outdoor applications such as wireless equipment or video surveillance equipment and indoor applications such as equipment used in factory automation or harsh industrial processes.

RJ45 connectors are not designed for high reliability in the presence of moisture, dust or corrosive elements. For this reason, the IP67 sealing ability of the RJ45-ECS connector system provides a reliable connection, even in very harsh environments, for many years of trouble free service. The shielded nature of the Cat5e cable and connectors provide maximum shielding against external EMI for consistent data communications.

For modern wireless systems, the quick disconnect feature allows for ready replacement of rooftop equipment, to minimize field time spent servicing customer’s equipment, and minimizing downtime for the customer. This helps to increase operator profitability and customer satisfaction.
