Enclosure 12x10x5" vented w/ mount plate. FRP NEMA Type 3R, 3X/IP24

$273.00
SKU:
HWN12V
Brand:

Availability:
In stock
Weight:
8.20 LBS
Write a Review

Enclosure Vented w/ Mount Plate

Rugged weatherproof enclosure that is ideal for both indoor and outdoor applications.

Constructed from molded halogen free self extinguishing fiberglass reinforced polyester (FRP), it is well suited for high temperature or corrosive environments. The integral mounting flange allows it to be wall mounted as well as on a flat surface without the need for extra mounting hardware. The fully gasketed lid features two stainless steel quick release latches and a continuous stainless steel hinge. The light grey color of the NB121005 series is cleaner, cooler and aesthetically pleasing. Users can enjoy the physical benefits of better heat reflection and better UV resistance due to the lighter color. The contoured body provides an attractive and contemporary appearance.

Features an aluminum mounting plate and holes in the enclosure for two Type-N bulkhead lightning protectors or connectors. In addition, a grounding lug and a cable conduit connector are provided

Features:

  • Molded fiberglass reinforced polyester (FRP)
  • Stainless steel quick release latches with padlock hasps
  • Fully gasketed raised vented lid with removable filters
  • NEMA Type 3R, 3X/IP24 rated
  • Features aluminum mounting plate

Applications:

  • Wireless LAN Wi-Fi equipment installations
  • Indoor and outdoor installation
  • Industrial control equipment installations
  • High temperature or corrosive environment
  • Hydraulic or pneumatic control installation

Specifications:

Enclosure Material Halogen free, self extinguishing fiberglass reinforced polyester
Enclosure Color Light Gray
Weight 3.7 kg
Outside Dimensions (max) 338x287x142mm
Inside Dimensions 304x254x142mm
Mounting Plate Materials .10in.(2.5mm) Thick Anodized Aluminum
Mounting Plate Dimensions 304 x 231mm
Cable Feed 1/2in. Cable Conduit Connector
Temperature Rating Continuous: -58°F to 302°F (-50° C to 150°C) Momentary exposure up to 392°F(200°C)
Flame Ratings UL 94-5V
RoHS Compliant Yes
Ratings

NEMA 3R, 3X / IP24
